Mechanical Test Fixture Kits

Cortek offers low cost, high quality mechanical test fixture kits for printed circuit board testing, debugging and programming. Offered in multiple sizes, our kits are easily customizable, size adaptable in every axis and can be re-tooled and re-used to meet the changing electronic needs while saving money on your investment. Z-Axis vs. Clamshell Comparison. Click here to see our Test Fixture Gallery

  • Mechanical Test Fixture Kit 0608 - Single, no handlesMechanical Test Kit 0608 Test Area up to 4.0” x 6.0” $395.00 Add To Cart
  • Mechanical Test Kit 1208Mechanical Test Kit 1208 Test Area up to 10.0” x 6.0” From: $495.00 Select Options
  • Z-Axis Test Fixture Kit - 1612Mechanical Test Kit 1612 Test Area up to 14.0” x 10.0” From: $595.00 Select Options
  • Mechanical Test Kit 2016Mechanical Test Kit 2016 Test Area up to 18.0” x 14.0” From: $695.00 Select Options
  • 1612 Z Axis Unit EZ-Axis Actuator for Fixture Kits From: $1,050.00 Select Options
  • Mechanical Test Kit 2420Mechanical Test Kit 2420 Test Area up to 22.0” x 18.0” $795.00 Add To Cart

Key Features

  • Go Green! When current lifecycle of application is complete, you can reuse base parts for next application.
  • Multiple heights available – unique custom size configurations readily available if our standard doesn’t meet your requirement.
  • More useable testable area for UUT compared to competition.
  • More useable area for height as a standard. Ability to increase height as an option in between push and pin plate.
  • Design is clean, streamlined and rugged and more adaptable compared to competition.
  • New latch bar design moves the latching posts outboard of the center UUT area making for easier UUT handling.
  • Easier for operator to use fixture because of accessibility improvements
  • Ease of side panel fabrication for I/O connections, switches or other hardware.
  • CTS custom designed hinges made of 6061 aluminum, black anodized.
  • Mechanical Spring Hinges
  • Rubber Feet
  • FR4 pin plate locking screw

Options:

  • Customization of fixture plates – submission of data required for quote
  • FR4, Acrylic, Polycarbonate ESD plates available
  • Installation of fixture hardware to include: Probes & Sockets, locating pins, push rods, side guides, connectors, interface pcb, interlocks, etc.
  • Wiring per customer specification
  • Safety shroud
  • Stripper plate
