Mechanical Test Kit - 0608 Test Area up to 4.0” x 6.0”

Model #: 0608

$850.00 $850.00

  • UUT Test Area: (W X D X H): 4.0” x 6.0“ x 2.0” (UUT may extend beyond test area)
  • Overall Dimensions: (W X D X H): 9.9” x 8.9” x 7.7” (dimensions include handles, hinges)
  • Weight: Approximately 7 lbs.
  • Hinged, no internal springs
  • Includes 6 ESD pushers/nuts

Check out our machining and design services. Visit our Gallery to see some examples of applications of this unit.

Key Features:

  • Go Green! When current lifecycle of application is complete, you can reuse base parts for next application.
  • Multiple heights available – unique custom size configurations readily available if our standard doesn’t meet your requirement.
  • More useable testable area for UUT compared to competition.
  • More useable area for height as a standard. Ability to increase height as an option in between push and pin plate.
  • Design is clean, streamlined and rugged and more adaptable compared to competition.
  • New latch bar design moves the latching posts outboard of the center UUT area making for easier UUT handling.
  • Easier for operator to use fixture because of accessibility improvements
  • Ease of side panel fabrication for I/O connections, switches or other hardware.
  • CTS custom designed hinges made of 6061 aluminum, black anodized.
  • Mechanical Spring Hinges
  • Rubber Feet
  • FR4 pin plate locking screw



Options:

  • Customization of fixture plates – submission of data required for quote
  • Additional FR4, Acrylic, Polycarbonate ESD plates available
  • Installation of fixture hardware to include: Probes & Sockets, locating pins, push rods, side guides, connectors, interface pcb, interlocks, etc.
  • Wiring per customer specification
  • Safety shroud
  • Stripper plate



Additional Information

Weight 10 lbs
